| range of product |
Modicon X80
|
|
|---|---|---|
| product or component type |
PTO module
|
|
| number of channels |
2
|
|
| number of inputs |
4
|
|
| discrete input type |
Current sink yes origin input conforming to IEC 61131-2 type 3
Current sink yes proximity input and limit switch input conforming to IEC 61131-2 type 3 Current sink or source counter in position input conforming to IEC 61131-2 type 3 Current sink or source drive ready, emergency input conforming to IEC 61131-2 type 3 |
|
| input compatibility |
2-wire/3-wire proximity sensor 19.2…30 V conforming to IEC 947-5-2
|
|
| output compatibility |
Signal converter (USIC)
RS422, 7 mA input Source input, 5 V to 24 V |
|
| output frequency |
200 kHz <0.5 m with USIC and VW3M8210R05
100 kHz <5 m with the normal source input circuit 200 kHz <10 m with the RS422 compatible circuits |
