| range of product |
Modicon X80
|
|
|---|---|---|
| product or component type |
Analog input module
|
|
| electrical connection |
40 ways 1 connector
|
|
| Isolation between channels |
Isolated
|
|
| input level |
Low level
|
|
| analogue input number |
4
|
|
| analogue input type |
Voltage +/- 1.28 V
Voltage +/- 160 mV Voltage +/- 320 mV Voltage +/- 40 mV Voltage +/- 640 mV Voltage +/- 80 mV Resistor 400 Ohm 2 wires Resistor 400 Ohm 3 wires Resistor 400 Ohm 4 wires Resistor 4000 Ohm 2 wires Resistor 4000 Ohm 3 wires Resistor 4000 Ohm 4 wires Temperature probe -100…+260 °C Cu 10 Temperature probe -100…+450 °C Pt 100 conforming to UL/JIS Temperature probe -100…+450 °C Pt 1000 conforming to UL/JIS Temperature probe -200…+850 °C Pt 100 conforming to IEC Temperature probe -200…+850 °C Pt 1000 conforming to IEC Temperature probe -60…+180 °C Ni 100 Temperature probe -60…+180 °C Ni 1000 Thermocouple +130…+1820 °C thermocouple B Thermocouple +270…+1300 °C thermocouple N Thermocouple -200…+600 °C thermocouple U Thermocouple -200…+760 °C thermocouple J Thermocouple -200…+900 °C thermocouple L Thermocouple -270…+1000 °C thermocouple E Thermocouple -270…+1370 °C thermocouple K Thermocouple -270…+400 °C thermocouple T Thermocouple -50…+1769 °C thermocouple R Thermocouple -50…+1769 °C thermocouple S |
