Eaton EMR6-I1-A-1 Faz Kontrol Rölesi Çözümleri

Overcurrent and undercurrent monitor, Current measuring range: 3 – 30 mA, 10 – 100 mA, 0.1 – 1 A, Supply voltage: 24 – 240 V AC, 50/60 Hz, 24 – 240 V DC

Current monitoring relays, Product range: EMR Measuring and monitoring relays, Monitoring of single-phase DC and AC networks, On delay: None = 0 or adjustable from 0.1 to 30 s, Extension of the measurement range possible with current transformers, Monitoring of: Overcurrent, Undercurrent, Current measuring range: I~/I= 3 – 30 mA, 10 – 100 mA, 0.1 – 1 A A, Supply voltage: 24 – 240 V AC, 50/60 Hz, 24 – 240 V DC, Mounting position: As required, Fixing: Snap fixing, top-hat rail IEC/EN 60715, Width: 22.5 mm, Standards: UL 508, CAN/CSA C22.2 No.14, GL, EAC, CCC, RMRS
